| Audio Features |
Full-duplex Hands-free Speakerphone with AEC Codecs: G.711(A/μ), G.722, G.723, G.729, G.726, iLBC DTMF: In-band, Out-of-band (RFC 2833) and SIP INFO VAD, CNG, AEC, PLC, AJB, AGC |
| Phone Book |
- Local Phonebook up to 1000 entries Black List
- XML Remote Phonebook
- Intelligent Search Method
- Phonebook Search/Import/Export
- Call History: Dialled/Received/Missed/Forwarded
|
| Phone Features |
- 1 VoIP Account
- Call Hold, Mute and DND
- One-touch Speed Dial and Hotline
- Redial, Call Return and Auto Answer
- Call Forward, Call Waiting and Call Transfer
- Local 3-way Conferencing
- Direct IP Call without SIP Proxy
- Ringtone Selection/Import/Delete
- Keypad Lock and Emergency Call
- Set Date and Time Manually or Automatically
- Dial Plan, XML Browser and Action URL/URI
- Instant Messaging (Web UI and Phone)
|
| Call Management |
- Anonymous Call (CLIR)
- Anonymous Call Rejection
- Message Waiting Indicator (MWI), Voicemail and Call Pickup
- Intercom, Paging and Music on Hold
- Call Completion and Hot-desking
- Dial-out Number from Web UI
|
| Display |
- 132×64-pixel Graphical LCD
- LED for Incoming/Ongoing Call, MWI, Mute and Hold
- Intuitive User Interface with Icons and Soft keys
- Multiple Languages
- Caller ID with Name and Number
|
| Networking and Security |
- SIP v1 (RFC2543), v2 (RFC3261)
- IPv6
- NAT Transverse: STUN Mode
- Proxy Mode and Peer-to-Peer SIP Link Mode
- IP Assignment: Static/DHCP/PPPoE
- HTTP/HTTPS Web Server
- Time and Date Synchronization using SNTPUDP/TCP/DNS-SRV (RFC 3263)
- QoS: 802.1p/Q Tagging (VLAN), Layer 3 ToS, DSCP
- SRTP for Voice
- Transport Layer Security (TLS)HTTPS Certificate Manager
- AES Encryption for Configuration File
- Digest Authentication using MD5/MD5-sess
- IEEE802.1
- XSNMP v1/v2
|
| Management |
- Configuration: Browser/Phone/Auto Provision
- Auto Provision via FTP/TFTP/HTTP/HTTPS for Mass
- Deploy
- Factory Reset
- Soft Reboot
- Package Tracing
- System Log
|
| Physical Features |
- 2 x 10/100 Mbps LAN and PC Ports
- 29 keys including 4 Soft Keys
- 1 x RJ9 Handset Port
- 1 x RJ9 Headset Port
- Dimension (W x D x H): 185 x 188 x 143 mm
|
| Mechanical: |
| Packaging |
10 Qty/CTN |
| Net Weight |
9.8 kg |
| Gross Weight |
10.8 kg |
| Gift Box |
215 x 200 x 121 mm |
| Installation |
Wall Mount, Table-top |
| Colour |
Grey |
| Environmental: |
| Operating Temperature |
-10° C to 50°C (14° F to 122° F) |
| Operating Humidity |
10 – 95% (Non-condensing) |
| Certifications |
CE, FCC-15 (Class B), RoHS |
